D-Link DGS-1100 Series Switch User Manual
Firmware Upgrade from HTTP
This window is used to initiate a firmware upgrade from a local PC using HTTP.
To view the following window, click Tools > Firmware Upgrade & Backup > Firmware Upgrade
from HTTP, as shown below:
Figure 13-3 Firmware Upgrade from HTTP window
The fields that can be configured are described below:
Parameter Description
Source File
Enter the source filename and path of the firmware file
located on the local PC. Alternatively click the Browse button
to navigate to the location of the firmware file located on the
local PC.
Click the Upgrade button to initiate the firmware upgrade.
Firmware Upgrade from TFTP
This window is used to initiate a firmware upgrade from a TFTP server.
To view the following window, click Tools > Firmware Upgrade & Backup > firmware Upgrade
from TFTP, as shown below:
Figure 13-4 Firmware Upgrade from TFTP window
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Enter the TFTP server’s IPv4 address here.
Source File
Enter the source filename and path of the firmware file
located on the TFTP server here.
Click the Upgrade button to initiate the firmware upgrade.
Firmware Backup to HTTP
This window is used to initiate a firmware backup to a local PC using HTTP.
To view the following window, click Tools > Firmware Upgrade & Backup > Firmware Backup to
HTTP, as shown below:
