D-Link DGS-1100 Series Switch User Manual
EEE
Energy Efficient Ethernet (EEE) is defined in IEEE 802.3az. It is designed to reduce the energy
consumption of a link when no packets are being sent.
To view the following window, click Green > EEE, as shown below:
Figure 12-3 EEE window
The fields that can be configured are described below:
Parameter Description
From Port / To Port
Select the appropriate port range used for the configuration
here.
State
Select this option to enable or disable the state of this feature
here.
Click the Apply button to accept the changes made.
Note: The EEE feature is only supported on the copper ports on all DGS-1100 Series switches.
