D-Link DGS-1100 Series Switch User Manual
Figure 6-3 SNMP Community Table Settings window
The fields that can be configured are described below:
Parameter Description
Access Right
Select the access right here. Options to choose from are
Read Only, and Read Write.
Read Only - SNMP community members using the
community string created can only read the contents of the
MIBs on the Switch.
Read Write - SNMP community members using the
community string created can read from, and write to the
contents of the MIBs on the Switch.
Community Name
Enter an alphanumeric string of up to 16 characters that is
used to identify members of an SNMP community. This
string is used like a password to give remote SNMP
managers access to MIB objects in the Switch’s SNMP
agent.
Click the Apply button to accept the changes made.
SNMP Host Table Settings
This window is used to configure and display the recipient of the SNMP notification.
To view the following window, click Management > SNMP > SNMP Host Table Settings, as shown
below:
Figure 6-4 SNMP Host Table Settings
The fields that can be configured are described below:
Parameter Description
Host IPv4 Address
Enter the IPv4 address of the SNMP notification host.
User-based Security
Model
Select the security model here. Options to choose from are
SNMPv1, and SNMPv2c.
SNMPv1 - Select to allow the group user to use the SNMPv1
security model.
SNMPv2c - Select to allow the group user to use the
SNMPv2c security model.
Community String
Enter the community string to be sent with the notification
packet.
Click the Apply button to accept the changes made.
