D-Link DGS-1100 Series Switch User Manual
8. Quality of Service (QoS)
802.1p Priority
Port Rate Limiting
802.1p Priority
This window is used to view and configure the port’s default CoS settings.
To view the following window, click QoS > 802.1p Priority, as shown below:
Figure 8-1 Port Default CoS window
The fields that can be configured for Port Scheduler Method are described below:
Parameter Description
From Port / To Port
Select the appropriate port range used for the configuration
here.
Scheduler Method SP - Denoting a Strict Priority scheduling will set the highest
queue to be emptied first while the other queues will follow
the weighted round-robin scheduling scheme
WRR - Use the weighted round-robin ( WRR ) algorithm to
handle packets in an even distribution in priority classes of
service.
Click the Apply button to accept the changes made.
The fields that can be configured Port Default CoS are described below:
Parameter Description
From Port / To Port
Select the appropriate port range used for the configuration
here.
Default CoS
Select the default CoS option for the port(s) specified here.
The priorities are Highest, High, Medium and Low.
Click the Apply button to accept the changes made.
