D-Link DGS-1100-24P User Manual

D-Link DGS-1100 Series Switch User Manual
15. Appendix B - Technical Specifications
Hardware
Specifications
Key Components /
Performance
Switching Capacity:
- DGS-1100-16: 32Gbps
- DGS-1100-18: 36Gbps
- DGS-1100-24: 48Gbps
- DGS-1100-26 : 52 Gbps
- DGS-1100-24P : 48Gbps
Max. Forwarding Rate:
- DGS-1100-16: 23.81Mpps
- DGS-1100-18: 26.79Mpps
- DGS-1100-24: 35.71Mpps
- DGS-1100-26 : 38.69Mpps
- DGS-1100-24P : 35.71Mpps
Forwarding Mode: Store and Forward
Packet Buffer memory:
- DGS-1100-16: 512Kbits
- DGS-1100-18: 1.5Mbits
- DGS-1100-24: 512Kbits
- DGS-1100-26 : 1.5Mbits
- DGS-1100-24P : 512Kbits
Flash Memory: 8M Byte
Port Functions
10/100/1000BaseTX ports compliant with
the following standards:
- IEEE 802.3 compliance
- IEEE 802.3u compliance
- IEEE 802.3ab compliance
- IEEE802.3at (Only DGS-1100-24 Port 1 ~
Port 12)
-Supports Full/half-Duplex operations at
10/100Mbps
-Supports Full-Duplex operation at
1000Mbps
-Supports IEEE 802.3x Flow Control
-Support Auto-Negotiation
-Compliant to IEEE 802.3az Energy
Efficiency Ethernet.
SFP ports compliant with the following
standards:
- IEEE 802.3u compliance
- IEEE 802.3z compliance
Physical &
Environment
DGS-1100-16/18/24/26/24P: AC input,
100~240 VAC, 50/60Hz, internal
universal power supply
Acoustic Value:
- DGS-1100-16/18/24/26: 0dB(A) (Fan-less)
- DGS-1100-26P: 44.5 dB(A)
Operation Temperature 0~50°C
Storage Temperature -10~70°C
Operation Humidity: 10%~95% RH
Storage Humidity: 5%~95% RH
Emission (EMI)
Certifications
FCC class A
CE Class A
VCCI Class A
BSMI
CCC
Safety Certifications
CUL, LVD, CB, CCC, BSMI
Features
L2 Features
DGS-1100-16/24/24P: 8K MAC address.
DGS-1100-18/26: 16K Mac address
Loopback Detection
Port Mirroring
Link Aggregation
Cable Diagnostics
Spanning Tree
L2 Multicasting
IGMP Snooping
VLAN
802.1Q VLAN standard
Port-Based VLAN
82

D-Link DGS-1100-24P Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	-
Networking standards	IEEE 802.3ab, IEEE 802.3aq, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Virtual LAN features	Voice VLAN, Port-based VLAN
DHCP features	DHCP client
MAC address entries	Static MAC address entries
Queue scheduling algorithms	SP, Weighted Round Robin (WRR)
Jumbo frames	9216
Forwarding rate	35.71 Mpps
Number of queues	96
MAC address table	8000 entries
Packet buffer memory	0.512 MB
Safety	UL/cUL, CE LVD
Certification	-FCC Class A\\r -CE Class A\\r -VCCI Class A
Product color	Black, Grey
Number of fans	1 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	128.3 W
Power consumption (typical)	21.2 W
Total Power over Ethernet (PoE) budget	100 W
Power over Ethernet plus (PoE+) ports quantity	12
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-5 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Noise level	27.6 dB
Flash memory	8 MB
Mean time between failures (MTBF)	563292 h
Package depth	362 mm
Package width	361 mm
Package height	104 mm
Package weight	3169 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1330 mm
Pallet height (sea)	2125 mm
Pallet gross weight (air)	306819 g
Pallet gross weight (sea)	499365 g
Quantity per pallet (air)	81 pc(s)
Quantity per pallet (sea)	135 pc(s)
Shipping (inner) case width	334 mm
Shipping (inner) case height	398 mm
Shipping (inner) case length	380 mm
Shipping (inner) case weight	10697 g
Shipping (inner) case net weight	9507 g
Number of cartons per pallet (air)	27 pc(s)
Number of cartons per pallet (sea)	45 pc(s)
Quantity per shipping (inner) case	3 pc(s)

Weight and Dimensions

Depth	230 mm
Width	280 mm
Height	44 mm
Weight	2150 g
