D-Link DGS-1100 Series Switch User Manual
LLDP
LLDP Global Settings
LLDP (Link Layer Discovery Protocol) provides IEEE 802.1AB standards-based method for switches
to advertise themselves to neighbor devices, as well as to learn about neighbor LLDP devices.
This window is used to configure the LLDP global settings.
To view the following window, click L2 Features > LLDP > LLDP Global Settings, as shown below:
Figure 7-303 LLDP Global Settings window
The fields that can be configured for LLDP Global Settings are described below:
Parameter Description
LLDP State
Select this option to enable or disable the LLDP feature
LLDP Trap State
Select this option to enable or disable the LLDP trap state.
Click the Apply button to accept the changes made.
LLDP Neighbor Port Information
This window is used to display the information learned from the neighbors. The switch receives
packets from a remote station but is able to store the information as local.
To view the following window, click L2 Features > LLDP > LLDP Neighbor Port Information, as
show below:
Figure 7-314 LLDP Neighbor Port Information window
