3 Getting Started D-Link Smart Managed Switch User Manual
2
2
1
1
3 Getting Started
This chapter introduces the management interface of D-Link Smart Managed Switch.
Management Options
The D-Link Smart Managed Switch can be managed through any port on the device by using the Web-based
Management.
Each switch must be assigned its own IP Address, which is used for communication with Web-Based
Management or a SNMP network manager. The PC should have an IP address in the same range as the
switch. Each switch can allow up to four users to access to the Web-Based Management concurrently.
Please refer to the following installation instructions for the Web-based Management.
Using Web-based Management
After a successful physical installation, you can configure the Switch, monitor the network status, and display
statistics using a web browser.
Supported Web Browsers
The embedded Web-based Management currently supports the following web browsers:
Web Browser via IE8(or later version), Firefox, Chrome and Safari.
Connecting to the Switch
You will need the following equipment to begin the web configuration of your device:
1. A PC with a RJ-45 Ethernet connection
2. A standard Ethernet cable
Connect the Ethernet cable to any of the ports on the front panel of the switch and to the Ethernet port on the
PC.
Figure 3.1Connected Ethernet cable
Login Web-based Management
In order to login and configure the switch via an Ethernet connection, the PC must have an IP address in the
same subnet as the switch. For example, if the switch has an IP address of 10.90.90.90, the PC should have
an IP address of 10.x.y.z (where x/y is a number between 0 ~ 254 and z is a number between 1 ~ 254), and
a subnet mask of 255.0.0.0. There are two ways to launch the Web-based Management, you may either click
the Web Access button at the top of the SmartConsole Utility or open the web browser and enter 10.90.90.90
(the factory-default IP address) in the address bar. Then press <Enter>.

Table of Contents

Other manuals for D-Link DGS-1210-52MP

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DGS-1210-52MP and is the answer not in the manual?

D-Link DGS-1210-52MP Specifications

General IconGeneral
PoE StandardIEEE 802.3af/at
PoE Budget370W
Switching Capacity104 Gbps
Forwarding Rate77.4 Mpps
MAC Address Table Size16K
Power Input100-240 VAC, 50/60 Hz
Ports48 x 10/100/1000BASE-T PoE+, 4 x Gigabit SFP
Jumbo Frame Support9216 Bytes
Dimensions440 x 250 x 44 mm
Operating Temperature0 to 50 °C
Storage Temperature-40 to 70 °C (-40 to 158°F)
Humidity5% to 95% non-condensing
