D-Link DGS-1210-52MP User Manual

4 Web-based Switch Configuration D-Link Smart Managed Switch User Manual
26
Figure 4.4 – SNMP in Smart Wizard
NOTE: Changing the system IP address will
disconnect you from the current connection.
Please enter the correct IP address in the Web
browser again and make sure your PC is in the
same subnet with the switch. See Login Web-
based Management for a detailed description.
NOTE: Standard
Mode and Surveillance Mode
Web UIs share the same configuration files. Any
features enables in one interface will be made
available in the other interface, for example: PoE
scheduling, SNMP settings
and the surveillance
VLAN in use.
If you want to change the settings, click Apply and start a new web browser.
Figure 4.5 – Confirm the changes of IP address in Smart Wizard

D-Link DGS-1210-52MP Specifications

General

PoE Standard	IEEE 802.3af/at
PoE Budget	370W
Switching Capacity	104 Gbps
Forwarding Rate	77.4 Mpps
MAC Address Table Size	16K
Power Input	100-240 VAC, 50/60 Hz
Ports	48 x 10/100/1000BASE-T PoE+, 4 x Gigabit SFP
Jumbo Frame Support	9216 Bytes
Dimensions	440 x 250 x 44 mm
Operating Temperature	0 to 50 °C
Storage Temperature	-40 to 70 °C (-40 to 158°F)
Humidity	5% to 95% non-condensing
