D-Link DIR-615 User Manual

DIR-615 Wireless N300 Router
User Manual
Configuring via Web-based Interface
Wi-Fi
In this menu you can specify all needed settings for your wireless network.
Basic Settings
On the Wi-Fi / Basic settings page, you can enable your wireless local area network (WLAN)
and configure its basic parameters.
Figure 123. Basic settings of the wireless LAN.
Parameter Description
Enable Wireless
The checkbox enables Wi-Fi connections. If you want to disable
your WLAN, deselect the checkbox.
Hide Access Point
If the checkbox is selected, other users cannot see your Wi-Fi
network. (It is recommended not to select this checkbox in order to
simplify initial configuration of your WLAN.)
SSID
A name for the WLAN. By default, the value DIR-615 is specified.
It is recommended to specify another name for the network upon
initial configuration (use digits and Latin characters).
Country
The country you are in. Select a value from the drop-down list.
Channel
The wireless channel number. When the auto value is selected, the
router itself chooses the channel with the least interference.
Page 150 of 208

D-Link DIR-615 Specifications

Wireless Signal Rates and Frequency

wireless signal rate	108Mbps • 48Mbps, 54Mbps - 24Mbps, 36Mbps - 12Mbps, 18Mbps - 9Mbps, 11Mbps - 5.5Mbps, 6Mbps - 1Mbps, 2Mbps
MSC wireless signal rate	130Mbps (270) - 117Mbps (243), 104Mbps (216) - 78Mbps (162), 66Mbps (135) - 58.5Mbps (121.5), 52Mbps (108) - 39Mbps (81), 26Mbps (54) - 19.5Mbps (40.5), 12Mbps (27) - 6.5Mbps (13.5)
frequency range	2.4GHz to 2.483GHz

Power and LEDs

transmitter output power	17dBm ± 2dB
LEDs	Power - Internet, WLAN - LAN (10/100)

Operating Environment

operating temperature	32°F to 104°F ( 0°C to 40°C)
humidity	95% maximum (non-condensing)
indoor use only	Yes

Weight and Dimensions

length	7.8 inches
width	5 inches
height	1.2 inches
