D-Link DIR-615 User Manual

DIR-615 Wireless N300 Router
User Manual
Configuring via Web-based Interface
MAC Filter
On the Firewall / MAC filter page, you can configure MAC-address-based filtering for computers
of the router's LAN.
Figure 149. The Firewall / MAC filter page.
To specify a new address for the MAC filter, click the Add button. In the line displayed, you can
specify the following parameters:
Parameter Description
MAC address
The MAC address of a device from the router's LAN. You can enter
the MAC address of a device connected to the router's LAN at the
moment. To do this, select the relevant device from the Known
IP/MAC addresses drop-down list (the field will be filled in
automatically).
Action
Select an action for the rule.
Deny: Blocks access to the router's network for the device with the
specified MAC address.
Allow: Allows access to the router's network and to the Internet for
the device with the specified MAC when the rules on the Firewall /
IP filters page block access for this device.
After specifying the needed parameters, click the Apply button.
Page 189 of 208

D-Link DIR-615 Specifications

Wireless Signal Rates and Frequency

wireless signal rate	108Mbps • 48Mbps, 54Mbps - 24Mbps, 36Mbps - 12Mbps, 18Mbps - 9Mbps, 11Mbps - 5.5Mbps, 6Mbps - 1Mbps, 2Mbps
MSC wireless signal rate	130Mbps (270) - 117Mbps (243), 104Mbps (216) - 78Mbps (162), 66Mbps (135) - 58.5Mbps (121.5), 52Mbps (108) - 39Mbps (81), 26Mbps (54) - 19.5Mbps (40.5), 12Mbps (27) - 6.5Mbps (13.5)
frequency range	2.4GHz to 2.483GHz

Power and LEDs

transmitter output power	17dBm ± 2dB
LEDs	Power - Internet, WLAN - LAN (10/100)

Operating Environment

operating temperature	32°F to 104°F ( 0°C to 40°C)
humidity	95% maximum (non-condensing)
indoor use only	Yes

Weight and Dimensions

length	7.8 inches
width	5 inches
height	1.2 inches
