D-Link DWR-932 User Manual

6D-Link DWR-932 User Manual
Section 2 - Installation
Initial Setup
Installation
This section will guide you through the installation process.
1. Ensure that your DWR-932 4G/LTE Mobile Router is powered o.
2. Remove the cover on the underside of the router, underneath the battery there is a slot
for your SIM card. Slide your SIM card into the slot provided, ensuring that the alignment
is the same as indicated by the logo next to the slot. The gold contacts on the card should
be facing downwards.
Note: Always unplug and turn o the router before installing or removing the SIM card. Never
insert or remove the SIM card while the router is in use.
3. Press and hold the power button on the top side of the router.
a. “Welcome” will be displayed on the screen as the router performs its initialization
processes.
b. After a few moments, the LCD will change to a home screen. The network name (SSID)
and password of the DWR-932 can be accessed from the LCD screen by pressing the
power button. For more details on the LCD display, please refer to “LCD Display” on
page 5.

D-Link DWR-932 Specifications

Radio Frequency Bands

FDD-LTE bands	Band 1, 3, 7, 8, 20
TDD-LTE band	38
UMTS bands	B1-2100 MHz / B8-900 MHz

Cellular Access

GSM bands	850/900/1800/1900 MHz
LTE output power class	23 dBm (class3)
Downlink speed	100 Mbps

Wi-Fi Specifications

Wi-Fi standard 1	802.11n
Wi-Fi standard 2	802.11g
Wi-Fi standard 3	802.11b

Physical Specifications

Dimensions	96.8 x 57.6 x 15 mm (3.81 x 2.26 x 0.59 inches)
Weight	90 g (3.17 ounces)
Antenna	One internal antenna

Operating Environment

Operating temperature	0 to 40 °C (14 to 131 °F)
USB interface	micro USB port
USIM slot	Standard 6-pin SIM card interface
