D-Link DWR-932 User Manual

54D-Link DWR-932 User Manual
Section 3 - Conguration
System
System Information
FW Version
Modem Version
Hardware Version
IMEI
SIM IMSI
Model Name
Battery Capacity
System Uptime
The DWR-932’s current rmware version.
The DWR-932’s current modem version.
The DWR-932’s current hardware version.
International Mobile Equipment Identity is a unique
number assigned to every mobile device.
The Subscriber Identication Module or SIM card
has a unique number called International Mobile
Subscriber Identity (IMSI). This is used to identify and
authenticate users on cellular devices.
The model name of your D-Link router.
Your router’s current battery life.
The length of time your system has been running for.
Note: The FW version number and Modem Version
number displayed on the image above will not be the
same as your router’s.
About DWR-932

D-Link DWR-932 Specifications

Radio Frequency Bands

FDD-LTE bands	Band 1, 3, 7, 8, 20
TDD-LTE band	38
UMTS bands	B1-2100 MHz / B8-900 MHz

Cellular Access

GSM bands	850/900/1800/1900 MHz
LTE output power class	23 dBm (class3)
Downlink speed	100 Mbps

Wi-Fi Specifications

Wi-Fi standard 1	802.11n
Wi-Fi standard 2	802.11g
Wi-Fi standard 3	802.11b

Physical Specifications

Dimensions	96.8 x 57.6 x 15 mm (3.81 x 2.26 x 0.59 inches)
Weight	90 g (3.17 ounces)
Antenna	One internal antenna

Operating Environment

Operating temperature	0 to 40 °C (14 to 131 °F)
USB interface	micro USB port
USIM slot	Standard 6-pin SIM card interface
