Daikin Altherma 3 GEO Installation Manual

5 Electrical installation
Installation manual
21
EGSAH/X06+10UDA9W
Daikin Altherma 3 GEO
4P598591-1A – 2019.12
5.9 To connect the space cooling/
heating ON/OFF output
Wires: (2+1)×0.75mm²
Maximum load: 3.5A, 250VAC
—
1 Open the following (see "3.2.1To open the indoor unit"[47]):
1 Top panel
3
2
5
1
4
2 User interface panel
3 Front panel
4 Installer switch box cover
5 Main switch box cover
2 Connect the alarm output cable to the appropriate terminals as
shown in the illustration below. Make sure to put wires 2 and 3
between the installer switch box and main switch box in a cable
sleeve (field supply) so that they are double insulated.
14a
21
YCY2
X2M
1
2
32
A4P
b
a
1+2 Wires connected to the alarm
output
3 Wire between the installer
switch box and main switch
box
a Installation of EKRP1HBAA is
required.
b Cable sleeve (field supply)
1×
2×
21
1×
b
a
X2M
14a
21
L
N
YC
Y2
1
2
3
1×
1×
b
3 Fix the cable with cable ties to the cable tie mountings.
