VLT is a registered Danfoss trademark
Intro-7
Ratings Table 380-500V
Mains supply 3 x 380-500 V
Model number
VLT 4152 VLT 4202 VLT 4252 VLT 4302 VLT 4352
VLT 5122 VLT 5152 VLT 5202 VLT 5252 VLT 5302
VLT 6152 VLT 6172 VLT 6222 VLT 6272 VLT 6352
VLT 8152 VLT 8202 VLT 8252 VLT 8302 VLT 8352
Normal overload current ratings (110 %):
Output current
Nominal [A] (380-440 V) 212 260 315 395 480
MAX (60 sec) [A] (380-440 V) 233 286 347 434 528
Nominal [A] (441-500 V) 190 240 302 361 443
MAX (60 sec) [A] (441-500 V) 209 264 332 397 487
Output Nominal
[
kVA
](
400 V
)
147 180 218 274 333
Nominal [kVA] (460 V) 151 191 241 288 353
Nominal [kVA] (500 V) 165 208 262 313 384
Typical shaft output [kW] (400 V) 110 132 160 200 250
[HP] (460 V) 150 200 250 300 350
[kW] (500 V) 132 160 200 250 315
High overload torque (160 %):
Output current
Nominal [A] (380-440 V) 177 212 260 315 395
MAX (60 sec) [A] (380-440 V) 266 318 390 473 593
Nominal [A] (441-500 V) 160 190 240 302 361
MAX (60 sec) [A] (441-500 V) 240 285 360 453 542
Output
Nominal [kVA] (400 V) 123 147 180 218 274
Nominal [kVA] (460 V) 127 151 191 241 288
Nominal [kVA] (500 V) 139 165 208 262 313
Typical shaft output
[kW] (400 V) 90 110 132 160 200
[HP] (460 V) 125 150 200 250 300
[kW] (500 V) 110 132 160 200 250
Power loss Normal overload [W] 2619 3309 4163 4977 6107
Power loss High overload [W] 2206 2619 3309 4163 4977
Limits and Ranges
Warning Voltage Low DC Bus V 423 423 423 423 423
Alarm Voltage Low DC Bus V 402 402 402 402 402
Warning Voltage High DC Bus V 817 817 817 817 817
Alarm Voltage High DC Bus V 855 855 855 855 855
Brake On Voltage DC Bus V 795 795 795 795 795
Brake On Voltage (Full Duty Cycle) DC Bus V 810 810 810 810 810
SMPS Start Voltage DC Bus V 360 360 360 360 360
SMPS Stop Voltage DC Bus V 330 330 330 330 330
Overcurrent Warning VLT Out 327 392 480 582 730
Overcurrent Alarm (1.5 sec delay) VLT Out 327 392 480 582 730
Earth Fault Alarm VLT Out 80 95 120 151 180
Heatsink Over Temperature Degrees C 75 80 95 95 105
Mains Phase Warning (5 sec delay) DC Bus Ripple VAC 50 50 50 50 50
Mains Phase Alarm (25 sec delay) DC Bus Ripple VAC 50 50 50 50 50
Fan On Low Speed Temperature Degrees C 45 45 45 45 45
Fan On High Sped Temperature Degrees C 50 50 50 50 50
Fan Off Temperature Degrees C <30 <30 <30 <30 <30
Fan Voltage Low Speed Fan VAC 200 200 200 200 200
Fan Voltage High Speed Fan VAC 230 230 230 230 230
