Datalogic Matrix 210 Programming Manual

MATRIX 210™ PARAMETERS LIST
27
4
4.3 COMMUNICATION
25 PIN CONNECTOR MODELS
ETHERNET MODELS
PARAMETER TYPE SEL STRING DATA
MAIN PORT
Data TX 1 1 ESC B A 0 = Disabled
1 = Enabled
Serial Interface Type 1 1 ESC B B 0 = RS232
1 = RS485
Communication
Protocol
1 1 ESC B C 0 = None
1 = MUX32
2 = Siemens 3964
3 = Siemens RK512
Multidrop Address 0 ESC B D Range: 0 to 31
Baud Rate 1 1 ESC B E 0 = 2400
1 = 4800
2 = 9600
3 = 19200
4 = 38400
5 = 57600
6 = 115200
Baud Rate
Multidrop bus
1 1 ESC B F 0 = 2400
1 = 4800
2 = 9600
3 = 19200
4 = 38400
5 = 57600
6 = 115200
Parity 1 1 ESC B G 0 = None
1 = Odd
2 = Even
Data Bits 1 1 ESC B H 0 = 7
1 = 8
Stop Bits 1 1 ESC B I 0 = 1
1 = 2
Communication
Handshake
1 1 ESC B J 0 = None
1 = XON/XOFF
2 = RTS/CTS
Header String 2 ESC B K Length: 0 to 128
Terminator String 2 ESC B L Length: 0 to 128
Reading Phase ON
String
2 ESC B M Length: 1 to 128
Acquisition Trigger
String
2 ESC B N Length: 1 to 128
Reading Phase OFF
String
2 ESC B O Length: 1 to 128
