HOST MODE PROGRAMMING
58
4
PARAMETER TYPE SEL STRING DATA
Output Format 1 1 ESC K Q 0 = % (on Last Samples)
1 = N/M (on Last Samples)
2 = %+N/M (on Last Samples)
3 = % (on All Samples)
4 = N/M (on All Samples)
5 = %+N/M (on All Samples)
Last Read Code TX 1 1 ESC K R 0 = Disabled
1 = Enabled
2 = Enabled With Code Center
3 = Enabled With Code Center And
Bounds
4.13 DIGITAL I/O
25 PIN CONNECTOR MODELS
ETHERNET MODELS
PARAMETER TYPE SEL STRING DATA
EXTERNAL TRIGGER
Active State 1 1 ESC M A 0 = Closed
1 = Open
Debounce Filter (ms) 1 1 ESC M B 0 = 0.5
1 = 1
2 = 5
3 = 10
4 = 0.1
INPUT 2
Active State 1 1 ESC M C 0 = Closed
1 = Open
Debounce Filter (ms) 1 1 ESC M D 0 = 0.5
1 = 1
2 = 5
3 = 10
4 = 0.1
OUTPUT 1
Line Function 1 1 ESC O a 0 = Standard
1 = External Lighting System
2 = External Fieldbus
3 = External Host Command
Line State 1 1 ESC O A 0 = Normally Open
1 = Normally Closed
Activation Events
(Match Code disabled)
3 28 ESC O B 0 = None
1 = Complete Read
2 = Partial Read
4 = No Read
8 = Acquisition Trigger
16 = Phase ON
32 = Phase OFF
64 = Run Mode
128 = Host Control Mode
256 = ISO-IEC Symbol Contrast
512 = ISO-IEC Print Growth
1024 = ISO-IEC / AIM DPM Axial Non-
Uniformity
