HOST MODE PROGRAMMING

A SPECIAL COMMANDS

ID-NET™ SPECIAL COMMANDS

The following special command allows to send strings to a Slave #N through the Master

device in an ID-NET™ reading system layout. In order to send this special command, it is not

necessary to switch the reader into Host Mode.

This special command can be used to send Reading Phase ON

, Acquisition Trigger and

Reading Phase OFF

strings (for One Shot and Phase Mode operating modes) to a Slave

device in an ID-NET™ reading system layout.

The Matrix 210™ 'Send String To Slave Device #N' special command must have the

following format:

<ESC> ( <B0

> ADDR STRING ) <ESC>

Where:

 ADDR:

Device Address

 STRING:

String To Send (Length: 1 to 32)

ADDR is a character indicating address of the device in an ID-NET™ Master/Slave reading

system layout:

ADDR = <30

> + <Device Address> where:

Device Address = 0:

Standalone device or Master ID-NET™ device

Device Address = 1 to 31:

Slave ID-NET™ device

Device Address = 32:

ID-NET™ broadcast address

This means:

ADDR = <30

>: Standalone device or Master ID-NET™ device

ADDR = <31

> to <4F

>: Slave ID-NET™ device

ADDR = <50

ID-NET™ broadcast address
