Datalogic Matrix 210 Programming Manual

HOST MODE PROGRAMMING
68
4
PARAMETER TYPE SEL STRING DATA
ACTIONS
Heartbeat TX Mode 1 1 ESC T l 0 = Conditioned
1 = Unconditioned
Heartbeat TX Timeout
(sec)
1 1 ESC T m 0 = 1
1 = 2
2 = 5
3 = 10
4 = 30
5 = 60
6 = 180
Main Port 1 1 ESC T U 0 = Disabled
1 = Enabled
FORMAT
Header String 2 ESC T X Length: 0 to 128
Terminator String 2 ESC T Y Length: 0 to 128
Heartbeat Message
Format
1 1 ESC T n 0 = Internal Numeric Messages
1 = User Defined Messages
USER DEFINED MESSAGES
Hearbeat Message 2 ESC T o Length: 0 to 128
4.17 MATCH CODE
25 PIN CONNECTOR MODELS
ETHERNET MODELS
PARAMETER TYPE SEL STRING DATA
MATCH CODE
Status 1 1 ESC P A 0 = Disabled
1 = Enabled
Symbology Check 1 1 ESC P B 0 = Disabled
1 = Enabled
Store Input 3 2 ESC P C 0 = None
1 = External Trigger
2 = Input 2
Right Code Message 2 ESC P D Length: 0 to 64
Wrong Code
Message
2 ESC P E Length: 0 to 64
Store Memory 1 1 ESC P F 0 = Temporary
1 = Permanent
MATCH CODE SLOT (DEPTH: n = 1 to 10)
Symbology #n 1 1 ESC y #n 0 = Interleaved 2of5
1 = Code 39
2 = Code 39 Full ASCII
3 = Codabar
4 = Code 128
5 = GS1-128 (ex EAN 128)
6 = Code 93
7 = EAN-13
8 = EAN-8
9 = UPC-A
10 = UPC-E
