Datalogic Matrix 210 Programming Manual

HOST MODE PROGRAMMING
36
4
4.7 CBX GATEWAY
25 PIN CONNECTOR MODELS + CBX HOST INTERFACE MODULES
ETHERNET MODELS + CBX HOST INTERFACE MODULES
PARAMETER TYPE SEL STRING DATA
HOST INTERFACE
Host Interface Type
1 1 ESC S A 0 = None
1 = Profibus
2 = DeviceNet
3 = Ethernet/IP
4 = CC-Link
5 = CAN Open
6 = Profinet IO
7 = Modbus TCP
8 = Ethernet TCP/IP
FIELDBUS
Data TX 1 1 ESC S B 0 = Disabled
1 = Enabled
Header String 2 ESC S D Length: 0 to 128
Terminator String 2 ESC S E Length: 0 to 128
Reading Phase ON
String
2 ESC S F Length: 1 to 128
Reading Phase OFF
String
2 ESC S G Length: 1 to 128
Acquisition Trigger
String
2 ESC S H Length: 1 to 128
PROFIBUS
Master Input Area Size 0 ESC S I Range: 8 to 144
Master Output Area
Size
0 ESC S J Range: 8 to 144
Node Address 0 ESC S K Range: 0 to 126
Data Flow Control 1 1 ESC S L 0 = Disabled
1 = DAD Driver
Data Consistency 1 1 ESC S M 0 = Disabled
1 = Enabled
DEVICENET
Master Input Area Size 0 ESC S N Range: 8 to 144
Master Output Area
Size
0 ESC S O Range: 8 to 144
Node Address 0 ESC S P Range: 0 to 64
Data Flow Control 1 1 ESC S Q 0 = Disabled
1 = DAD Driver
Data Consistency 1 1 ESC S R 0 = Disabled
1 = Enabled
