Datalogic Matrix 210 Programming Manual

HOST MODE PROGRAMMING
66
4
4.16 DIAGNOSTICS
25 PIN CONNECTOR MODELS
ETHERNET MODELS
PARAMETER TYPE SEL STRING DATA
HEARTBEAT
Status 1 1 ESC T k 0 = Disabled
1 = Enabled
DIAGNOSTICS
Status 1 1 ESC T A 0 = Disabled
1 = Enabled
Refresh Time (sec) 1 1 ESC T B 0 = 1
1 = 2
2 = 5
3 = 10
4 = 30
5 = 60
Slave Diagnostics
(Master/Slave)
1 1 ESC T C 0 = Disabled
1 = Enabled
Slave Diagnostics
(ID-NET Network)
1 1 ESC T D 0 = Disabled
1 = Enabled
Local Network Failure 1 1 ESC T E 0 = Disabled
1 = Enabled
LEDs Activation On
Slave Failure
(Master/Slave)
1 1 ESC T F 0 = Disabled
1 = Enabled
LEDs Activation On
Slave Failure
(ID-NET Network)
1 1 ESC T G 0 = Disabled
1 = Enabled
FieldBus
Communication Failure
1 1 ESC T H 0 = Disabled
1 = Enabled
FieldBus Type Mismatch 1 1 ESC T I 0 = Disabled
1 = Enabled
FieldBus Configuration
Error
1 1 ESC T J 0 = Disabled
1 = Enabled
Fieldbus DHCP Problem ESC T K
Wrong Rotary Switch
Selection
1 1 ESC T L 0 = Disabled
1 = Enabled
CBX BM100
Communication Failure
1 1 ESC T M 0 = Disabled
1 = Enabled
ACTIONS
Heartbeat TX Mode 1 1 ESC T l 0 = Conditioned
1 = Unconditioned
Heartbeat TX Timeout
(sec)
1 1 ESC T m 0 = 1
1 = 2
2 = 5
3 = 10
4 = 30
5 = 60
6 = 180
TX Mode 1 1 ESC T Q 0 = On Timeout
1 = With Code
Message Position 1 1 ESC T R 0 = Append to Code
1 = Replace Code
