Datalogic PowerScan PD9600 User Manual

CM9681-N100 WITH DISABLED AIDA LED MODE
PRODUCT REFERENCE GUIDE 379
CM9681-N100 WITH DISABLED AIDA LED MODE
BF/NS LED (Network Status)
SF/MS LED (Module Status)
Link/Activity
CM9681-N200
BF/NS LED (Network Status)
SF/MS LED (Module Status)
LED STATE COMMENTS
Off No connection
Green Connected with IO controller in RUN state
Green (1 flash) Connected with IO controller in STOP state
Red Major internal error (combined with a red MS LED)
Red, flashing
Station name not set
IP address not set
Other configuration error
LED STATE COMMENTS
Off No power or module in setup
Green Normal operation
Green, flashing Diagnostic event(s) present
Red
Device in EXCEPTION state
Major internal error (combined with a red NS LED)
LED STATE COMMENTS
Off No communication present
Green Ethernet link established
Green, blinking Ethernet link established, communication present
LED STATE COMMENTS
Off No power or no IP address
Green Online, one or more connections established
Green, flashing Online, no connections established
Red Duplicate IP address, FATAL error
Red, flashing One or more connections timed out
LED STATE COMMENTS
Off No power
Green Run state
