Description Notes
MB: Breaker Static sync. of the MB is set to Breaker Sync.
MB: Infinite Static sync. of the MB is set to Infinite Sync.
4.12 Logic
These events are not available in bus tie breaker controllers.
Description Notes
Not used -
TRUE = Always
FALSE = Never
4.13 Digital inputs
4.13.1 Digital inputs
Description Required option Notes
Dig. input No [23-27] -
The number indicates the terminal number for the input in question.
Dig. input No [29-35] M13.2
Dig. input No [43-55] M12
Dig. input No [65-71] M13.4
Dig. input No [91-97] M13.6
Dig. input No 102 -
Dig. input No 105 -
Dig. input No 108 -
Dig. input No [112-117] -
Dig. input No [127-133] M13.8
Ext. I/O Dig. In [1-16] H12.2, H12.8
4.13.2 CIO digital inputs
Only available if the CIO modules are enabled.
Description
Notes
CIO 116 no. 1. In. 10
to CIO 116 no. 3. In. 26
The event is active when the terminal is energised.
4.14 Modes
Mode events available for each controller type
Description
Genset Mains Bus tie breaker Group Plant Notes
Island ● ● ● ●
One or more generators running in island mode
are not connected to the mains grid.
AMF ● ● ● ● AMF (Automatic Mains Failure) function mode.
Application note 4189341276B EN Page 27 of 50
