Deif AGC-4 Mk II User Manual

Description Notes
Select application [1-4] Power management: Select the application from the controller.
Open BTB Open the bus tie breaker.
Close BTB Close the bus tie breaker.
Select three phase system Sets the controller to work in a three-phase system.
Select split L1L3 phase system Sets the controller to work in a two-phase system (L1-L3).
Select split L1L2 phase system Sets the controller to work in a two-phase system (L1-L3).
Select single phase system Sets the controller to work in a single-phase system (L1).
Reset horn Reset the horn relay.
Reset I max. demand Reset the peak current detected in the controller.
Reset I thermal demand Reset the thermal current detected in the controller.
Pulse counter [1-2] Increase the selected pulse counter.
Reset pulse counter [1-2] Reset the selected pulse counter.
Set parameter [1-2] Select the parameter set for nominal settings.
Ack. BB protection alarms
Acknowledges all busbar alarms including: 1270-1430, 1660, 1700, 1960, 1970,
7480-7490.
Access lock Activates access lock.
Direct close on dead BA and dead BB
See Special M-Logic function - BTB direct close in Option G5 Power
management.
Direct close breaker on dead BA or dead BB
See Special M-Logic function - BTB direct close in Option G5 Power
management.
Breaker configuration: Normal Close See Tie breaker configuration in Option G5 Power management.
Breaker configuration: Normal Open See Tie breaker configuration in Option G5 Power management.
Assume all BTB POS fdb OFF in case of pos
fail or ID missing
Fault handling procedure.
More information
See Option G5 Power management for information about BTB commands.
5.1.4 Group tie breaker controller commands
Commands for group tie breaker
Description
Notes
Island Island function mode.
AMF AMF (Automatic Mains Failure) function mode.
Peak shaving Peak shaving function mode.
Fixed power Fixed power function mode.
Mains power export Mains power export function mode.
Load take over Load take over function mode.
Genset group
Semi-Auto mode Semi-auto running mode.
Test mode Test running mode.
Auto mode Auto running mode.
Application note 4189341276B EN Page 39 of 50

Deif AGC-4 Mk II Specifications

General

Brand	Deif
Model	AGC-4 Mk II
Category	Controller
Language	English
