Description Notes
Access lock Activates access lock.
Alternative start Activates alternative start.
Select L1L2L3 phase rotation Activates L1L2L3 as phase rotation direction
Select L1L3L2 phase rotation Activates L1L3L2 as phase rotation direction
5.1.6 M-Logic and AOP alarms
Output, Command - M-Logic and AOP
Description
Notes
M-Logic alarm [1-5] Activates the M-Logic alarm. Configure these alarms in menus 3570 to 3610.
M-Logic ext alarm [1-4] : Start
extended timer
Starts the timer configured in parameters 3621 to 3652. Use the parameters to select the
units for the timer and configure the alarm. When the timer runs out, the alarm is activated.
Auto reset: The timer is automatically reset when the alarm event is no longer present.
Manual reset: The timer is paused (but not reset) if the alarm event is no longer present.
The timer thus corresponds to the total time that the alarm event is present. The timer is
only reset when the M-Logic reset command is used.
M-Logic ext alarm [1-4] : Reset
extended timer
Resets the timer.
5.1.7 General purpose PID commands
These commands are only available for genset controllers.
Description
Notes
PID [1-6] activate Activates the PIDs.
PID [1-6] force min. outp. Forces the PID output to minimum.
PID [1-6] force max. outp. Forces the PID output to maximum.
PID [1-6] reset Resets the PID outputs.
PID [1-6] freeze output Freezes the PID outputs
5.2 Modes
Modes for genset (Output, Modes)
Description
Notes
Island Island function mode.
AMF AMF (Automatic Mains Failure) function mode.
Peak shaving Peak shaving function mode.
Fixed power Fixed power function mode.
Mains power export Mains power export function mode.
Load take over Load take over function mode.
Power management Power management function mode.
Remote maintenance Remote transformer maintenance.
Dry alternator Dry alternator function mode (DVC 550 required).
Application note 4189341276B EN Page 43 of 50
