4.20 Heavy consumers
These events are only available in genset controllers.
More information
See the document ALC-4 Designer's reference handbook for information about Heavy consumer events.
4.21 EIC events
These events are only available in genset controllers.
More information
See Options H12 and H13 Engine communication for information.
4.22 DAVR events
These events are only available in genset controllers.
DVC 310 event
More information
See Option T2 Digital AVR 4189340771 on the DVC 310 documentation page for more information.
DVC 550 events
More information
See Configure the DVC 550 with the AGC-4, M-Logic related to DVC 550 in the DVC 550 Designer's handbook for
more information about DAVR events.
4.22.1 DAVR PSS events
Description Notes
PSS Off The DAVR power system stabiliser function is off.
PSS enabled AND inactive
The DAVR power system stabiliser function is enabled, but it is not active because the load is
below the threshold.
PSS enabled AND active The DAVR power system stabiliser function is active.
PSS feature present in DAVR The DAVR power system stabiliser function is present.
4.23 General purpose PID
These events are only available in genset controllers.
Description
Notes
PID [1-6] active Indicates that the PID is active.
PID [1-6] at min. output Indicates when the PID is at minimum output.
PID [1-6] at max. output Indicates when the PID is at maximum output.
PID [1-6] output frozen Indicates that the PID is frozen.
PID [1-6] using input [1-3] Indicates which PID input is active.
PID [1-6] Modbus control Indicates if the PID is controlled by Modbus.
Application note 4189341276B EN Page 31 of 50
