Description Notes
Add DG Adds DG to the power management system.
Remove DG Removes DG from the power management system.
Select yes on the display Selects yes on the display in easy connect mode.
Select no on the display Selects no on the display in easy connect mode.
Enable Easy connect Enables Easy connect for the power management system.
Disable Easy connect Disables Easy connect for the power management system.
5.19 Grid support
These commands are only available for genset and mains controllers.
Description
Notes
Activate Power Ramp [1-4] Activate power ramp [1-4].
Var Reg Type Normal Activate normal var regulation.
Var Reg Type Q/U U_SHIFT See Option A10.
Var Reg Type Q/P REG CURVE See Option A10.
Var Reg Type Q/U Q_SHIFT See Option A10.
Var Reg Type FIXED COSPHI See Option A10.
Var Reg Type FIXED Q See Option A10.
Var Reg Type SUPERIOR See Option A10 (only in genset controllers).
Set Q(u) variant A ext. control to OFF Set Q(u) variant A external control to OFF.
Set Q(u) variant A ext. control to MODBUS Set Q(u) variant A external control to MODBUS.
Set Q(u) variant A ext. control to ANALOGUE Set Q(u) variant A external control to ANALOGUE.
Set Q(u) variant C ext. control to OFF Set Q(u) variant C external control to OFF.
Set Q(u) variant C ext. control to MODBUS Set Q(u) variant C external control to MODBUS.
Set Q(u) variant C ext. control to
ANALOGUE
Set Q(u) variant C external control to ANALOGUE.
Enable droop curve [1-2] See Option A10.
Disable droop curve [1-2] See Option A10.
Droop curve 2: Activate cosphi reference See Option A10.
Droop curve 2: Activate Q reference See Option A10.
Use Pset Min(Modbus/AI) See Option A10.
5.20 Power limit inputs
These commands are only available for genset controllers.
Description
Notes
Power Limit Input (1-4) Configure binary input 1 to 4 for RRCR (Radio Ripple Control Receiver) signals.
Application note 4189341276B EN Page 50 of 50
