Expansion cards and expansion card riser
An expansion card in the system is an add-on card that can be inserted into an expansion slot on the system board or riser card to
add enhanced functionality to the
system through the expansion bus.
NOTE: A System Event Log (SEL) event is logged if an expansion card riser is unsupported or missing. It does not
prevent your system from turning on and no BIOS POST message or F1/F2 pause is displayed.
NOTE: The expansion card riser is optional for systems with four hard drives.
Expansion card installation guidelines
Your system supports PCIe Express Generation 3 cards. The following table provides riser congurations for R330 systems:
Table 23. Expansion card slots available on the expansion card riser
PCIe slot on the expansion card
riser
Height Length Link width Slot width
LP SLOT 1 Half Height Half Length x4 x8
FH SLOT 2 Full Height Half Length x8 x16
Table 24. Expansion card slots available on the system board
PCIe slot on the system board Height Length Link width Slot width
PCIE_G3_X4 Half Height Half Length x4 x8
NOTE: The expansion cards are not hot-swappable.
The following table provides a guide for installing expansion cards to ensure proper cooling and mechanical t. The expansion cards
with the highest priority must be installed rst using the slot priority indicated. All other expansion cards must be installed in card
priority and slot priority order.
Table 25. Expansion card installation order
Card priority Card type Slot priority Maximum allowed
1 RAID PowerEdge RAID
Controller (PERC)
H730 and H330
Internal PERC slot 1
PERC H830 Full
Height
2 1
PERC H830 Low
Prole
1 1
2 10 Gb NICs Intel and Broadcom
Dual Port
2 1
Intel and Broadcom
Dual Port Low
Prole
1 1
3 FC8 HBA Qlogic QLE2562,
Qlogic QLE2560,
Emulex LPE12002,
Emulex LPE12000,
Emulex LPE15000,
2 1
92
