Dell EMC PowerEdge R750xs 60KKP User Manual

Figure 27. Removing a cooling fan
Next steps
Replace the cooling fan.
Installing a cooling fan
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
Steps
Align and slide the cooling fan into the cooling fan cage until the fan clicks into place.
NOTE: Install high-performance fan (Gold Grade) in the Fan 1 slot while installing rear drive module.
Installing and removing system components 39

Dell EMC PowerEdge R750xs 60KKP Specifications

General

Form Factor	2U rack server
Processor	Up to 2 x Intel Xeon Scalable processors, up to 32 cores per processor
Memory	Up to 2TB DDR4, 3200MT/s, 16 DIMM slots
Storage	Up to 12 x 3.5" SAS/SATA (HDD/SSD)
RAID Controller	PERC H745, H755, HBA355i
Network	1GbE, 10GbE, 25GbE
Power Supply	1100W
