Quad-Port Mezzanine Cards
The following table illustrates the I/O module port mapping for full-height blades with quad-port mezzanine cards.
NOTE: For a detailed mapping of each PowerEdge system, see Quadport Capable Hardware for the M1000e
Modular Chassis at support.dell.com/manuals.
Table 5. Example of I/O Module Port Assignments - PowerEdge M610x in Slot 2
Blade n and Blade (n + 8)
NOTE: n denotes a
variable value from 1
to 8.
I/O Module
B1 C1 C2 B2
Mezz_FAB_B_Blade
n_Port1
Port n
Mezz_FAB_B_Blade
n_Port2
Port n
Mezz_FAB_B_Blade
n_Port3
Port (n+16)
Mezz_FAB_B_Blade
n_Port4
Port (n+16)
Mezz_FAB_C_Blade
n_Port1
Port n
Mezz_FAB_C_Blade
n_Port2
Port n
Mezz_FAB_C_Blade
n_Port3
Port (n+16)
Mezz_FAB_C_Blade
n_Port4
Port (n+16)
Mezz_FAB_B_Blade n
+8_Port1
Port (n+8)
Mezz_FAB_B_Blade n
+8_Port2
Port (n+8)
Mezz_FAB_B_Blade n
+8_Port3
Port (n+24)
Mezz_FAB_B_Blade n
+8_Port4
Port (n+24)
Mezz_FAB_C_Blade n
+8_Port1
Port (n+8)
Mezz_FAB_C_Blade n
+8_Port2
Port (n+8)
Mezz_FAB_C_Blade n
+8_Port3
Port (n+24)
44
