• Integrated LOM2 connection 2 connects to I/O module A2, port 21.
Dual-Port Mezzanine Cards
For a half-height blade in bay n :
• The integrated NIC connects to I/O module A1, port n and I/O module A2, port n .
• Mezzanine card B connects to I/O module B1, port n and I/O module B2, port n .
• Mezzanine card C connects to I/O module C1, port n and I/O module C2, port n .
For example, in a blade in slot 12, the integrated NIC connects to I/O module A1, port 12 and I/O module A2, port 12.
Table 7. Example of I/O Module Port Assignments - Half-Height Blade 1
Blade 1 I/O Module
A1 B1 C1 C2 B2 A2
Integrated NIC Port 1 Port 1
Mezzanine Card C Port 1 Port 1
Mezzanine Card B Port 1 Port 1
The following figure shows the port connections for a half-height blade in bay 1 with two mezzanine cards.
46
