6
Technical Specifications
Enclosure Specifications
Power Supply Module
AC/DC power supply (per power supply)
Wattage 2700 W
Connector IEC C20
Heat dissipation 1205 BTU/hr (maximum)
Maximum inrush current Under typical line conditions and over the entire system
ambient operating range, the inrush current may reach 55 A
per power supply for 10 ms or less.
System voltage requirements 16 A, 100 V AC to 240 V AC, 50 Hz/60 Hz
DC/DC power supply (per power supply)
Wattage 2700 W
Connector Molex # 394260002 at PSU end, mating connector Molex #
39422-0012
Heat dissipation 1205 BTU/hr (maximum)
Maximum inrush current Under typical input voltage conditions and over the entire
system ambient operating range, the inrush current may
reach 120 A per power supply for 10 ms or less.
System voltage requirements 75 A, 48 V DC to 60 V DC
Optional Avocent iKVM Module
Externally accessible connectors
USB Two 4-pin, USB 2.0-compliant connectors for keyboard and
mouse support
ACI port RJ-45
Video 15-pin VGA
Chassis Management Controller Module
Externally accessible connectors
Remote management Two dedicated 10/100/1000 Mb RJ-45 (for integrated
Ethernet remote access controller). Gb port connects to the
97
