Hinge Cover 105
24
Hinge Cover
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information,
see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
CAUTION: Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
CAUTION: To help prevent damage to the system board, remove the main battery
(see "Removing the Battery" on page 15) before working inside the computer.
Removing the Hinge Cover
1
Follow the instructions in "Before You Begin" on page 9.
2
Remove the battery (see "Removing the Battery" on page 15).
3
Follow the instructions from step 3 to step 4 in "Removing the Optical
Drive" on page 17.
4
Remove the four screws that secure the hinge cover to the computer base.
5
Remove the keyboard (see "Removing the Keyboard" on page 27).
6
Remove the palm-rest assembly (see "Removing the Palm-Rest Assembly"
on page 31).
7
Remove the display assembly (see "Removing the Display Assembly" on
page 89).
book.book Page 105 Friday, April 13, 2012 2:02 PM
