Keyboard 27
7
Keyboard
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information,
see the Regulatory Compliance Homepage at
www.dell.com/regulatory_compliance.
CAUTION: Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
CAUTION: To help prevent damage to the system board, remove the main battery
(see "Removing the Battery" on page 15) before working inside the computer.
Removing the Keyboard
1
Follow the instructions in "Before You Begin" on page 9.
2
Remove the battery (see "Removing the Battery" on page 15).
CAUTION: The keycaps on the keyboard are fragile, easily dislodged, and time-
consuming to replace. Be careful when removing and handling the keyboard.
3
Turn the computer over and open the display as far as possible.
CAUTION: Do not slide the plastic scribe under the keyboard tabs to remove the
keyboard as it may cause permanent damage to the keyboard tabs.
4
Slide a plastic scribe between the slots on the keyboard and release the
tabs on the plam rest.
5
Pry and lift the keyboard to disengage it from the tabs on the palm rest.
book.book Page 27 Friday, April 13, 2012 2:02 PM
