42 Power-Button Board
Replacing the Power-Button Board
1 Follow the instructions in "Before You Begin" on page 9.
2 Slide the power-button board under the tab on the palm-rest assembly.
3 Replace the screw that secures the power-button board to the palm-rest
assembly.
4 Adhere the power-button board cable to the palm-rest assembly.
5 Turn the palm-rest assembly over.
6 Replace the palm-rest assembly (see "Replacing the Palm-Rest Assembly"
on page 35).
7 Replace the keyboard (see "Replacing the Keyboard" on page 29).
1 screw 2 power-button board cable
3 power-button board
1
3
2
