Display 95
2
Align the screw holes on the display panel with the screw holes on the
display back cover and replace the eight screws.
3
Route the display cable and Mini-Card antenna cables through the routing
guides on the display back cover.
4
Replace the display bezel (see "Replacing the Display Bezel" on page 93).
5
Replace the display assembly (see "Replacing the Display Assembly" on
page 91).
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
Display Cable
Removing the Display Cable
1
Follow the instructions in "Before You Begin" on page 9.
2
Remove the display assembly (see "Removing the Display Assembly" on
page 89).
3
Remove the display bezel (see "Removing the Display Bezel" on page 92).
4
Remove the display panel (see "Removing the Display Panel" on page 94).
5
Turn the display panel over and place it on a clean surface.
6
Lift the tape that secures the display cable to the display-board connector
and disconnect the display cable.
book.book Page 95 Friday, April 13, 2012 2:02 PM
