22 Module Cover
Replacing the Module Cover
1
Follow the instructions in "Before You Begin" on page 9.
2
Align the tabs on the module cover with the slots on the computer base
and gently snap the cover in place.
3
Tighten the captive screw that secures the module cover to the computer
base.
4
Replace the battery (see "Replacing the Battery" on page 16).
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
1 captive screw 2 module cover
3 tabs (3)
book.book Page 22 Friday, April 13, 2012 2:02 PM
