Keyboard 29
Replacing the Keyboard
1
Follow the instructions in "Before You Begin" on page 9.
2
Slide the keyboard cable into the connector on the system board. Press
down on the connector latch to secure the keyboard cable to the connector
on the system board.
3
Slide the tabs on the keyboard into the slots on the palm rest.
4
Gently press around the edges of the keyboard and slide it upwards to
secure the keyboard under the tabs on the palm rest.
5
Close the display and turn the computer over.
1 keyboard cable 2 keyboard-cable connector
book.book Page 29 Friday, April 13, 2012 2:02 PM
