Installing coin cell battery
Steps
1. Affix the coin cell battery on the slot inside the computer.
2. Route the coin cell battery cable through the routing channel before connecting the cable.
3. Connect the coin cell battery cable to the connector on the system board.
4. Connect the battery cable to the connector on the system board.
5. Install the base cover.
6. Follow the procedure in After working inside your computer.
WWAN card
Removing WWAN card
Steps
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Disconnect the battery cable from the connector on the system board.
4. To remove the WWAN card:
a. Remove the M2.0 x 3.0 screw that secures the metal bracket to the WWAN card [1].
NOTE: The WWAN card pops out by an angle 15°.
Removing and installing components 23
