Port and connector specifications
Table 6. Temperature specifications
Feature Specifications
Audio Four-channel high definition audio Microphone-in, stereo
headphones, and headset combo connectorRealtek ALC3246
ControllerStereo conversion: 24-bit (analog-to-digital and
digital-to-analog)Internal interface - high-definition audio
codecExternal interface - microphone-in and stereo
headphones/speakers universal connector
Speakers: Power: 2X2 Wrms
Internal speaker amplifier: Two watts per channel
Internal microphone: Digital microphone (dual microphone with
camera)
No volume control buttons
Support hot-key keyboard button
Network adapter One RJ-45 connector
USB Two Type-C USB 3.1 Gen 1 DisplayPort (optional
Thunderbolt)Two USB 3.1 Gen 1 ports (one PowerShare
capable
Memory card reader MicroSD 4.0 card reader and One 3042, One 2280 M.2 slot
Micro Subscriber Identity Module (SIM) card External tray tied to WWAN hinge up
Docking port Dell Business Dock WD15 (optional)Dell Business Thunderbolt
Dock TB16 (optional) Noble Wedge Lock slot External USB
Type-C Doc
Express Card None
AC adapter E5 65 W
E5 65 W rug (Only for India)
E5 90 W
E4 65 W HF (BFR/PVC Free)
Power Companion 45 W (Dura Ace)
Hybrid Power Bank and adapter (45 W) (12 inches only, not
14/15) (No express charge)
Smart card reader One (optional)
Video HDMI 1.4
Communication specifications
Features
Specification
Network adapter Intel i219LM Gigabit Ethernet Controller 10/100/1000 Mb/s(RJ-45)
Wireless
● No WLAN option
● Qualcomm QCA61x4A 2x2 AC + Bluetooth 4.1 (non vPro)
● Qualcomm QCA6174A XR 2x2 AC + Bluetooth 4.1 (non vPro)
● Intel Dual-Band Wireless-AC 8265 2x2 + Bluetooth 4.2 (non vPro)
● Mobile Broadband Options (optional)
56 System specifications
