Viewing RMON Statistics
Remote Monitoring (RMON) contains links for viewing network information from a remote location. To
open the RMON page, click Statistics/RMON→ RMON in the tree view.
Viewing RMON Statistics Group
The RMON Statistics Group page contains fields for viewing information about device utilization and
errors that occurred on the device. To open the RMON Statistics Group page, click Statistics/RMON→
RMON→ Statistics in the tree view.
Figure 8-1. RMON Statistics Group

Dell PowerConnect 2816 Specifications

General

Ports	16 x 10/100/1000BASE-T
Switching Capacity	32 Gbps
Forwarding Rate	23.8 Mpps
VLAN Support	Yes, up to 256 VLANs
Rack Mountable	Yes, 1U
Relative Humidity	10% to 90% non-condensing
Management	Web-based, CLI
MAC Address Table Size	8K MAC addresses
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C
Jumbo Frame Support	Yes
Dimensions	440 x 257 x 44 mm (17.3 x 10.1 x 1.7 in)
