Dell PowerConnect 2816 User Manual

Dell PowerConnect 28xx Systems User Guide 37
Switching Port Default Settings
The following table gives the port default settings.
Table 3-3. Port Default Settings
Function Default Setting
Port speed and mode 10/100/1000BaseT copper: auto-negotiation full duplex
Port forwarding state Enabled
Port tagging No tagging
Flow Control On
Back Pressure Off (disabled on ingress)
MDIX (not user-configurable) On (relevant to coppers ports only)

Dell PowerConnect 2816 Specifications

General

Ports	16 x 10/100/1000BASE-T
Switching Capacity	32 Gbps
Forwarding Rate	23.8 Mpps
VLAN Support	Yes, up to 256 VLANs
Rack Mountable	Yes, 1U
Relative Humidity	10% to 90% non-condensing
Management	Web-based, CLI
MAC Address Table Size	8K MAC addresses
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C
Jumbo Frame Support	Yes
Dimensions	440 x 257 x 44 mm (17.3 x 10.1 x 1.7 in)
