Dell PowerEdge 1950 Installation Guide

Four-Post Rack Installation 9
Static Rails Rack Kit Contents
• One pair of static mounting rails with either VersaRails brackets or RapidRails brackets.
• One pair of chassis static rail modules
• 10-32 x 0.5-inch flange-head Phillips screws (8) (VersaRails kits only)
• Releasable tie wraps (2) (not shown in Figure 1-2)
NOTE: The nonmetric screws described in illustrations and in procedural steps are identified by size and number
of threads per inch. For example, a #10 Phillips-head screw with 32 threads per inch is identified as a 10-32 screw.
Figure 1-2. Static Rails Rack Kit Contents
1 10-32 x 0.5-inch flange-head
Phillips screws (8)
(VersaRails kits only)
2 static mounting rails (2) 3 chassis static rail modules (2)
FRONT
L
1
3
2

Dell PowerEdge 1950 Specifications

General

Processor Sockets	2
Chipset	Intel 5000X
Memory Slots	8 DIMM slots
Network	Dual embedded Broadcom NetXtreme II 5708 Gigabit Ethernet
Form Factor	1U Rack
Processor	Intel Xeon 5100, 5300 series
Memory	Up to 32GB DDR2
Storage	SAS or SATA
Drive Bays	Two 3.5" SAS or SATA drives or Four 2.5" SAS or SATA drives
RAID Controller	PERC 5/i, PERC 6/i
Power Supply	670W redundant power supply (optional)
Operating System Support	Microsoft Windows Server, Red Hat Linux, SUSE Linux
