Dell PowerEdge 1950 Installation Guide

Two-Post Rack Installation 37
Installing the System in the Rack
CAUTION: If you are installing more than one system, install the first system in the lowest available position
in the rack.
1 Place one hand on the front-bottom of the system and the other hand on the back-bottom of the
system.
2 Lift the system into position so that the side rails at the back of the system are aligned with the
mounting rails in the rack.
CAUTION: Because of the size and weight of the system, never attempt to install the system in the mounting rails
by yourself.
3 Push the system into the mounting rails until the system stops.
4 Push in and turn the thumbscrews on each side of the front chassis panel to secure the system to the
rack.
Removing the System From the Rack
To remove the system from the rack, perform the following procedure:
1 Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2 Loosen the thumbscrews on each side of the front chassis panel that secures the system to the rack.
3 Disconnect all cables from the system.
4 Pull the system out of the rack until it stops because of the release latches.
5 Push down on the release latches on each side of the system (see Figure 1-10).
6 Pull the system completely out of the rack.

Dell PowerEdge 1950 Specifications

General

Processor Sockets	2
Chipset	Intel 5000X
Memory Slots	8 DIMM slots
Network	Dual embedded Broadcom NetXtreme II 5708 Gigabit Ethernet
Form Factor	1U Rack
Processor	Intel Xeon 5100, 5300 series
Memory	Up to 32GB DDR2
Storage	SAS or SATA
Drive Bays	Two 3.5" SAS or SATA drives or Four 2.5" SAS or SATA drives
RAID Controller	PERC 5/i, PERC 6/i
Power Supply	670W redundant power supply (optional)
Operating System Support	Microsoft Windows Server, Red Hat Linux, SUSE Linux
