270
Installing Enclosure Components
Figure 4-3.
Removing and Installing a Fan Module
Installing a Fan Mod
ule
1
Inspect the fan for debris
before installing the fan in the enclosure.
2
Slide the fan module into the enclosur
e until it is fully sea
ted and the
release button engages. See
F
igur
e
4-3.
1
fan module
2
release button
1
2
269
271
