Dell PowerEdge M610 User Manual

Installing Enclosure Components 277
Figure 4-7. Removing and Installing the Bezel
Installing the Enclosure Bezel
1 Attach the bezel to the enclosure using the screws. See Figure 4-7.
2 Connect the ribbon cable to the LCD module, and reinstall the cover
plate.
1 bezel 2 enclosure
3 screws (8)
1
2
3
