326 System Board Information
PowerEdge M610x System Board
Figure 7-7. PowerEdge M610x System Board Connectors
9 - Hard-drive backplane connector
10 B1 – B6 Memory modules B1 – B6
11 - RAID battery connector
12 CPU1 Processor 1 socket
13 - iDRAC6 enterprise card connector
Table 7-13. PowerEdge M610 System Board Connectors
(continued)
Connector Description
3
7
13
1
2
4
12
9
11
8
6
5
10
