Technical Overview 19
Pin Number Signal name 18-AWG Wire Color
1 +3.3 VDC Orange
2 +3.3 VDC/SE Orange
3 COM Black
4+5 VDC Red
5 COM Black
6+5 VDC Red
7 COM Black
8POK Gray
9 +5 VFP Purple
10 +12 VD DC/SE Yellow/White
11 +12 VD DC Yellow/White
12 +3.3 VDC Orange
13 +3.3 VDC Orange
14 -12 VDC Blue
15 COM Black
16 PS_ON Green
17 COM Black
18 COM Black
19 COM Black
20 N/C N/A
21 +5 VDC/SE Red
22 +5 VDC Red
23 +5 VDC Red
24 COM Black
book.book Page 19 Monday, January 7, 2008 2:53 PM
