Removing the Front I/O Panel
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
1
Follow the procedures in "Before You Begin" on page 9.
2
Remove the computer cover (see "Removing the Computer Cover" on
page 13).
3
Remove any full-length expansion cards (see "Removing PCI and PCI
Express Cards" on page 32).
NOTICE: Carefully note the routing of each cable before you disconnect it, so that
you are sure to re-route cables correctly. An incorrectly routed or a disconnected
cable could lead to computer problems.
4
Disconnect the cables from the master I/O board.
5
Remove the card fan cage (see "Removing the Card Fan" on page 69)
6
Disconnect the
FRONT_AUDIO_USB_LED
cable, the FRONT_USB_LED
cable, and the USB_MB cable from the front I/O panel.
7
Remove the drive panel (see "Removing the Drive Panel" on page 53).
8
Remove the front panel:
a
Release the four tabs that secure the front panel to the chassis.
b
Carefully, pivot the front panel away from the computer to release it
from the chassis.
c
Disconnect the FRONT_LED cable from the front panel to remove
the front panel.
