Drives 53
Drive Panel
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
Removing the Drive Panel
1
Follow the procedures in "Before You Begin" on page 9.
2
Remove the computer cover (see "Removing the Computer Cover" on
page 13).
3
Grasp the drive-release latch and slide it towards the base of the computer
until the drive panel snaps open.
4
Pivot the drive panel outward and lift it from its side hinges.
5
Set the drive panel aside in a secure location.
1 drive-release latch 2 drive panel
3 drive-panel tabs (3)
2
1
3
