Denon AVR-887 User Manual

Basic Operation Basic Operation
30
ENGLISH
ENGLISH
Selecting the DTS NEO:6 mode
It is possible to play analog input signals and digital input signals (2-
channels) in the surround mode.
Press SURROUND PARAMETER.
Play a program source.
Press
FF GG
to select the play mode.
2
3
4
Press [STANDARD] to select “DTS NEO:6”.
DOLBY PLIIx
NEURAL SURROUND
DTS NEO:6
1
CINEMA:
This mode is optimum for playing movies. Decoding is performed
with emphasis on separation performance to achieve the same
atmosphere with 2-channel sources as with 6.1-channel sources.
MUSIC:
This mode is suited mainly for playing music.
Selecting the NEURAL SURROUND mode
It is possible to play analog input signals and digital input signals (2-
channels) in the surround mode.
This is the optimum mode for playing sources recorded in XM HD
Surround ( page 38, 39).
Play a program source.
Press SURROUND PARAMETER.
Press [STANDARD] to select “NEURALSURROUND”.
1
3
2
Press
DD HH
to select the item, then press
FF GG
to set.
Press ENTER or SURROUND PARAMETER.
5
4
DOLBY PLIIx
NEURAL SURROUND
DTS NEO:6
Press
DD HH
to select the item, then press
FF GG
to set.
When “MUSIC” mode is selected:
Press ENTER or SURROUND PARAMETER.
CNTR. IMAGE:
The expansion of the center channel can be adjusted. (0.0 to 1.0,
default : 0.3)
5
6
3
5
(When “MUSIC” is selected)
OFFSET:
Displays the dialog normalization offset value.
FLAG:
“MATRIX” is displayed if the input signal has undergone matrix
processing, “DISCRETE” is displayed if the input signal has undergone
discrete processing.
SIGNAL:
Displays the type of input signal.
fs:
Displays the input signal’s sampling frequency.
Checking the input signals
Press [ON SCREEN].
1
Press [ON SCREEN] again.
OSD-1 : Input signal
OSD-2 : HDMI monitor information
OSD-3 : Input/output settings
OSD-4 : Auto surround mode
OSD-5 ~ 7 : USER MODE 1 ~ 3
OSD-8 ~ 14 : Tuner preset stations
2
• “OSD-1”-“FLAG” is not displayed if there is no FLAG identification
signal in the input signal.
• OSD-2:
The monitor’s resolution is displayed when an HDMI monitor is
connected to the AVR-887.
• OSD-4:
This is displayed when the auto surround mode is set to “ON” (
page 57) and the input mode is set to “AUTO”.
It is not displayed when the input mode is set to “ANALOG” or
“EXT. IN”.
1
Example: Dolby Digital Example: DTS
FORMAT:
Displays the input signal’s number of channels (front / surround /
LFE on/off).
“SURROUND” is displayed for 2-channel signal sources recorded
in Dolby Surround.
Room EQ:
Displays the type of equalizer currently set.

Denon AVR-887 Specifications

Power

rated output front	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output front alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output center	100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output center alternative	135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround back	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround back alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
power supply	AC 120 V, 60 Hz
power consumption	5.5 A

Audio Inputs and Outputs

analog inputs	9 sets
analog ext inputs	8
digital inputs optical	4
digital inputs coaxial	2
audio delay function	0 - 200 msec.
variable subwoofer crossover	40/60/80/90/100/110/120/150/200/250 Hz

Video Inputs and Outputs

component video inputs	3 sets
composite inputs	5
s-video inputs	5
component video outputs	1 set
composite outputs	3
s-video outputs	3

Audio Performance

frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	100 dB (IHF-A weighted)
tone control treble	±6 dB at 10 kHz
tone control bass	±6 dB at 100 Hz

Weight and Dimensions

dimensions	17-3/32” (W) x 6-47/64” (H) x 16-27/64” (D)
dimensions metric	434 (W) x 171 (H) x 417 (D) mm
weight	29 lbs 5 oz
weight metric	13.0 kg
